CBD Series Walkie Electric Pallet Truck
Agile Transit, Trusted Pallet Handling — LI‑UNILIFT
Busy back‑of‑house zones and compact warehouses call for nimble pedestrian pallet trucks that navigate tight aisles while delivering solid payload performance. The CBD15/20‑Y walkie electric pallet truck delivers 1.5‑ton and 2‑ton load capacities, and accepts multiple battery choices to match different shift‑length demands for daily pallet transport.
Compact Sturdy Build for Restricted Work Zones
The CBD15/20‑Y pallet truck keeps a streamlined overall footprint that excels within narrow storage aisles and crowded workshop layouts. Heavy‑duty steel forks handle repeated pallet entry‑and‑exit cycles without excessive deformation. Users can select fork outer widths of 560 mm or 685 mm to align with common local pallet sizes.
Operators may pick maintenance‑free lead‑acid or lithium‑iron phosphate battery packs to suit site power arrangements. A high‑power controller sustains 10‑percent fully‑loaded gradeability, so the truck copes with gentle warehouse ramps without power drop‑off. Polyurethane wheels deliver quiet rolling movement across indoor concrete floors, while optional side‑mount balance wheels add extra travel stability for heavier payloads.
Human‑Centered Controls for Low‑Fatigue Daily Work
Every operating component is refined to simplify pallet moving tasks and ease operator burden through long work periods.
- Separated layout for handle and hydraulic cylinder creates remarkably light steering effort. Operators complete frequent turning maneuvers with minimal physical strain even during continuous shifts.
- A multifunctional tiller integrates key switch, upright travel button and an LCD readout. This screen displays remaining battery charge, working hours and fault codes; optional password lock and turtle‑speed mode expand operational flexibility.
- External charger design removes the need to move the whole truck near fixed charging bays. Teams complete battery replenishment at convenient locations across the warehouse floor.
Multi‑Layer On‑Board Safety for Pedestrian Operation
Critical safety hardware comes fitted as standard to shield staff and goods during pallet transit. Emergency stop switch and emergency reverse device respond rapidly once operators face unexpected obstacles along travel paths.
Electromagnetic braking holds the truck firmly stationary on sloped surfaces. This reliable brake system prevents unintended rolling while operators load or unload pallets. All core electrical circuits sit under monitoring from the main controller, which limits output to defend against overload‑related component harm.
Service‑Friendly Layout to Cut Repair Intervals
Thoughtful mechanical layout lowers inspection complexity and shortens downtime during planned maintenance work.
- Clamshell‑style metal housing opens wide, granting technicians quick access to internal motors, wiring and hydraulic assemblies.
- Clear LCD fault‑code display speeds troubleshooting and helps maintenance crews pinpoint issues without extra diagnostic gear.
- Swap‑compatible lead‑acid and lithium‑iron phosphate battery formats offer flexible upgrade paths for growing warehouse operations.
- Modular wheel assemblies simplify replacement for PU drive, support and load wheels after long‑term abrasion.
Evolving Compact Walkie Pallet Truck Intralogistics Solutions
Today’s small‑to‑mid‑size warehouses and retail distribution spaces seek cost‑effective pedestrian pallet trucks that balance agility, flexible battery options and dependable safety performance. The CBD15/20‑Y walkie electric pallet truck merges narrow‑aisle adaptability, strong climbing capability and service‑oriented mechanical design for workshops, retail stockrooms and compact fulfilment sites.
Beyond core payload performance, our engineering team keeps practical usability front‑of‑mind, from light steering force to readable onboard diagnostics. This compact walkie pallet truck streamlines routine pallet transport and helps facility managers contain ongoing material‑handling expenditures.
Technical Specifications
| Feature | unit | ||||||||||||||
| Load capacity | kg | 1500 | 2000 | ||||||||||||
| Wheels type | PU | ||||||||||||||
| Wheel quantity Driving wheel/Balance wheel/Bearing wheel | 1/2/4 | ||||||||||||||
| Outside width between forks | mm | 560/685 | |||||||||||||
| Inside width between forks | mm | 250/375 | |||||||||||||
| Fork length | mm | 1150/1200 | |||||||||||||
| Overall length | mm | 1700/1750 | |||||||||||||
| Overall width | mm | 677 | |||||||||||||
| Travel speed,laden/unladen | km/h | 4/4.5 | |||||||||||||
| Gradeability,laden/unladen | % | 6/16 | |||||||||||||
| Drive control type | DC | ||||||||||||||
